Since QueueMetrics 19.04.1, QueueMetrics offers a stable WebRTC softphone based on the JsSIP library. This softphone can be used by agents, through the QueueMetrics Realtime Agent Page, or by supervisors and administrators through the Wallboard Page. This new feature allows agents to work without the need for a physical phone, while supervisors can monitor calls in realtime without leaving the wallboard page. In this tutorial we will go through all the steps needed to set up and start using the softphone.

The WebRTC technology requires both QueueMetrics and Asterisk to work with HTTPS to guarantee the appropriate level of security. For this reason we need to make sure that QueueMetrics is running in https.

For detailed instructions on how to setup QueueMetrics in HTTPS, you can refer to the following section of our advanced configuration manual.

What we need to do now, is to create an extension for one of our agents. This will allow the agent to register to the PBX using its own QueueMetrics Softphone, by using this extension.

To create an extension, access FreePBX Administrator page and head to Applications ⇒ Extensions ⇒ Add extension ⇒ Add new Chan_SIP extension.

Here we will enter the data for our extension and linked user.

Click on Submit and then Apply Config to finalize the extension creation.

We then need to enable WebRTC for this extension so we click on the edit symbol under Actions and we go to the Advanced tab.

Here we need to set the following options:

Transport must be set to All - WSS Primary

Enable AVPF must be set to Yes

Force AVP must be set to Yes

Enable ICE Support must be set to Yes

Enable rtcp Mux must be set to Yes

Enable Encryption must be set to Yes (SRTP only)

Click On Submit then on Apply Config

Now we need to go to Admin ⇒ User Management to enable WebRTC for this user.

Click on the Edit Symbol under Action then go to the UCP tab.

From there we go to the Phone tab.

Note: at this point if this is a fresh FreePBX Installation, a message will appear saying the following:

This means that the extension cannot be allowed to be used through WebRTC, because it needs an SSL certificate to ensure an HTTPS connection for the extension.

To fix this, we have two different ways:

Creating your own Self-Signed Certificate, is a valid solution if you are only connecting to your extension from inside your own network. A self signed certificate is essentially a "homemade" certificate, not guaranteed by a Certificate authority.

To create a self signed certificate, we need to go to Admin ⇒ Certificate Management.

Here we can click on New Certificate ⇒ Generate Self-Signed Certificate, and input the following information:

We click on Generate Certificate to generate the certificate.

This will bring us back to the Certificate Management page, where we need to do one last thing.

If we do not have other certificates set on the system, we need to move our mouse to the empty cell beneath the Default column in the table. This will show a grey Check symbol in the cell, basically allowing you to set this certificate as the default SSL Certificate for your extensions. We need to click on the empty cell to set this certificate as the default certificate.

Now that we set this certificate as the default for our system, we can head back to the Phone tab in user 800’s settings.

We should now see that there is an option to Enable Phone, that we have to set to yes.

and set Enable WebRTC Phone to yes, we click on Submit then Apply Config.

Then we need to go back to the extension settings in Applications ⇒ Extensions ⇒ Edit Extension (pencil icon on the right) ⇒ Advanced, and set

We click on Submit then Apply Config, and move on to the next section.

To Create and agent, linked to the Asterisk Extension we created earlier, go to Edit Agents → Create New.

We call the agent Agent/800 and fill in the Agent Description field as we please. We then fill the following fields:

We click on Save then go back to the Homepage.

Now we need to create a User for Agent/800, so we go to Edit Users → Create New.

We set the Login field to 800, the Password to 800 and we set the Class field to AGENTS.

We click on Save and we go back to the homepage.

The last thing we need to do is to set one parameter in the Explore System Parameters page. Scroll down to the end of the page untill you see the following parameter: Web Socket URL for the connection.

We need to set this parameter to:

Using the correct IP address for our FreePBX machine. Then we Save at the bottom.

The last step we need to do, is to add a security exception in our browser for the WebSocket we just configured.

To do this, log out from QueueMetrics and go to the following url:

Where 10.10.5.162 must be substituted with your own PBX Address. This will trigger a security warning from your browser (Probably), and you need to acknowledge the warning and add the source as a security exception.

Once you do that, you should see a Not Found error. This is normal and it means that the exception was added correctly.

Now we’re good to go! We go back to our QueueMetrics login page, and we login as Agent/800.

From the Widget Menu we select Soft Phone and here is our WebRTC client.

Since QueueMetrics 19.04.1, the Wallboard page includes a Softphone panel, with the same features as the one present in the agent page.

After completing the previous configuration process, it is very easy to setup, as we merely need two steps to accomplish this:
